Description
Classic Elegance Meets Modern Safety – Dual Socket Design
Product Specifications
Construction:
-
Solid brass construction with polished finish
-
Nickel-plated brass contacts
-
Thermoplastic rear housing
Electrical Ratings:
-
13A per socket (total 26A)
-
250V AC, 50Hz
-
BS 1363 compliant
Safety Features:
-
Child-proof safety shutters
-
Reinforced earth terminal
-
Fire-retardant housing (UL94 V-0)
Dimensions:
-
86mm x 86mm faceplate
-
25mm minimum backbox depth
Key Features
✔ Premium Conductivity: Thick brass terminals minimize voltage drop
✔ Secure Connection: Extra-wide terminal screws (accepts 1.5-4mm² cable)
✔ Durability: 20,000+ insertion cycles
✔ Easy Installation: Pre-marked L/N/E terminals
✔ Timeless Style: Antique brass finish
Technical Performance
Contact Resistance: <5mΩ
Insulation Resistance: >100MΩ
Dielectric Strength: 4000V AC
Operating Temp: -25°C to +70°C
